These V97 electric locks were specially designed for inside and outside doors and pedestrian gates that open outwards. This is necessary when safety regulations foresee an outward-opening escape route in the event of an emergency. The characteristics and finish make the painted versions ideal for inside wooden doors; the galvanized versions are best for outside metal doors and gates, even in surroundings subject to considerable temperature ranges.
Installation: horizontal.
Backset: adjustable from 50 to 80 mm, by means of a simple operation with the Allen key supplied.
Double replaceable coil: which distributes the load uniformly and ensures a long working life.
Voltage: standard 12V AC (on request 12V DC; 24V AC or DC).
Case: one-piece galvanized steel.
Cover: galvanized steel (or galvanized and painted steel).
Handle: nylon, and nylon cylinder ring nut.
Latch: solid brass, self-locking with the device locked.
Ejector: nickel-plated steel, separate from the latch to ensure the correct working of the lock even if there is vertical adjustment between the lock and the striker (caused by weather changes).
Cylinders: solid brass, fixed internal, fixed or loose external.
Keys: supplied with 3 Viro profile nickel-plated brass keys.
Versions available with universal profile keys to replace the most common electric locks already installed without the need to withdraw keys in use. (Cylinders can be re-keyed with keying kit).
Mechanism:
brass pins;
mushroom brass counterpins, pick-resistant;
phosphor bronze pin springs.
Strikers:
inox stainless steel plate, with nylon guide (only for painted versions with a galvanized base) for installation on walled door jambs;
standard, steel, for narrow frames;
both strikers are specifically designed for outward opening doors and gates.
Supplied with: inox stainless steel strikers, brass cylinder ring nut (for painted versions with a galvanized base), nylon guide, roof-plate (for galvanized versions), Allen key for backset adjustment and fixing screws.
Packaging: single box.
On request:
galvanized steel roof-plate (item 8992.0600).
available anthracite metallic painted versions, add the required color code .469 to the item code.
